Sirio Boomerang W
 Sirio Boomerang WSirio Boomerang W
Sirio

Sirio Boomerang W


Ref:  0927W
Brand:  Sirio

Weight:  780g

Availability:



Product information

The Sirio Boomerang W is an omnidirectional CB & 10 Meter Homebase Antenna.

It is factory tuned at the md-band. It can also be tuned by adjusting the tapered fibre glass whip.

It comes complete with mounting bracket & clamps and can be mounted outside or in a loft.

Specifications

Electrical Data:

  • Type: 1/4 λ ground plane boomerang
  • Radiation: Omnidirectional
  • Polarization: Linear vertical
  • Frequency range: 26.8 ... 27.6 MHz Tunable
  • Systems: 10m-HAM
  • Gain: 0 dBd, 2.15 dBi
  • Bandwidth: ≥ 800KHz @ SWR ≤ 2
  • Max Power: 300 Watts (CW) continuous
  • 900 Watts (CW) short time
  • Connector: UHF-female (SO-239)


Mechanical Data:

  • Materials: Aluminium, Copper, Galvanized steel, Fiberglass, Nylon
  • Height (approx): 2.18m / 7.15 ft
  • Weight (approx): 750 gr / 1.65 lb
  • Mounting type: On-Mast
